1. Power Supply

3 phase, 5 wires  (380v, 50HZ)

2. Power Installed

400KW

3. Power Used

350 KW

4. Electric wire

3×120mm²+1×50mm²+1×25mm²

5. Compressed Air Supply

0.6~0.8Mpa

6. Compressed Air Absorption

5000 Nl/min

7. Machine Size

35.0m× 8.5m× 4.2m(L× W× H )

8. Working Size

40m× 12.0m ´5.0m  (L× W× H )

9. Machine Weight

About 70T (whole production line)

10. Machine Color:

 Blue ( confirm with customer)

11. Machine Direction:

From Right to Left   (can be designed as customer’s demand)

12. Containers:

6´ 40 HQ containers

13. Finish Product Size:

XL、L、M、S

( Based on Customer’s requirement)

  Max

 Min

Length

 1000mm

450mm

Width

 880mm

350mm

14. Product Structure:

Basic structure:   Fluff core, SAP, top sheet, backsheet, frontal tape, side tape, leg elastic, ADL
Optional structure: Double core, waistband, stand cuff, ADL, Fasten belt(T-tape).
